應用由不同長度的熱收縮套管搭配所需工具配件組裝而成, 依客戶不同使用需求, 可調整熱縮管數量, 規格, 顏色, 長度和配件樣式. 可拆式的隔板, 方便靈活設計不同的組裝空間, 放置合適的配件搭配施工使用. 活動式的手提盒型式組裝盒, 用於電線結合，連接，標識，環境保護和電纜修復等方面, 同時提供了經濟和優異的電氣和電子技術的解決方案。
The convenient and portable assortment kit that includes heat shrinkable tubing in different pre-cut pieces and in various colors and sizes to satisfy, splicing, connecting, identification, environmental protection and cable repair applications. The adjustable partition plates for designing various proper spaces to assemble splices, terminals, connectors and tools to satisfy different applications. It’s an economical and excellent solution for electrical and electronics technicians. -
特性盒子內容物：熱收縮套管,熱收縮端子
盒子規格: 27.5*19.5*5.2 cm
包裝材料顏色:透明PP
可調式分隔板:透明PP
K1 Adjustable partition
K1系列可變換式隔格 -
操作溫度範圍
-
認證 / 規範
-
顏色標準顏色:黑 紅 藍 黃 白 綠
Standard color ：black、white、red、blue、yellow、green
|
Part Number K1-101 |
||||
|
G5 Heat shrinkable tube / 內容物：G5熱收縮套管 |
||||
|
ITEM NO. 產品名稱. |
Nominal Size(mm) 尺寸(毫米) |
Length(inch) 長度(英吋) |
Color & Quantity彩色&數量 |
|
|
G5 |
3.0 |
6” |
Red |
45 PCS |
|
G5 |
4.5 |
6” |
Yellow |
25 PCS |
|
G5 |
6.0 |
6” |
Blue |
20 PCS |
|
G5 |
9.0 |
6” |
green |
10 PCS |
|
G5 |
12 |
6” |
white |
10 PCS |
|
G5 |
18 |
6” |
black |
10 PCS |
|
Part Number K1-102 |
|||
|
AIS Dual wall polyolefin tubing / AIS通用型含膠熱收縮套管 |
|||
|
ITEM NO. 產品名稱 |
Nominal Size(mm) 尺寸(毫米) |
Length(inch) 長度(英吋) |
Black & Quantity 黑色&數量 |
|
AIS |
3.2 |
6” |
25pcs |
|
AIS |
4.8 |
6” |
20pcs |
|
AIS |
6.4 |
6” |
15pcs |
|
AIS |
12.7 |
6” |
5pcs |
|
AIS |
19.1 |
6” |
3pcs |
|
AIS |
25.4 |
6” |
2pcs |
|
Part Number K1-201 |
||||
|
G5 Heat shrinkable tube / G5熱收縮套管 |
||||
|
ITEM NO. 產品名稱 |
Nominal Size(mm) 尺寸(毫米) |
Length(inch) 長度(英吋) |
Color & Quantity彩色&數量 |
|
|
G5 |
3.0 |
4” |
Red |
45 PCS |
|
G5 |
4.5 |
4” |
Yellow |
25 PCS |
|
G5 |
6.0 |
4” |
Blue |
20 PCS |
|
G5 |
9.0 |
4” |
green |
10 PCS |
|
G5 |
12 |
4” |
white |
10 PCS |
|
G5 |
18 |
4” |
black |
10 PCS |
|
AIS Dual wall polyolefin tubing / AIS通用型含膠熱收縮套管 |
||||
|
ITEM NO. 產品名稱 |
Nominal Size(mm) 尺寸(毫米) |
Length(inch) 長度(英吋) |
Black & Quantity黑色&數量 |
|
|
AIS |
3.2 |
2” |
25pcs |
|
|
AIS |
4.8 |
2” |
20pcs |
|
|
AIS |
6.4 |
2” |
15pcs |
|
|
AIS |
12.7 |
2” |
5pcs |
|
|
AIS |
19.1 |
2” |
3pcs |
|
|
AIS |
25.4 |
2” |
2pcs |
|
|
Part Number K1-301 |
||||||||
|
G5 Heat shrinkable tube / G5熱收縮套管 |
||||||||
|
ITEM NO. 產品名稱. |
Nominal Size(mm) 尺寸(毫米) |
Length(inch) 長度(英吋) |
Color & Quantity 彩色&數量 |
|||||
|
G5 |
3.0 |
2” |
Red |
45 pcs |
||||
|
G5 |
4.5 |
2” |
Yellow |
25 pcs |
||||
|
G5 |
6.0 |
2” |
Blue |
20 pcs |
||||
|
G5 |
9.0 |
2” |
green |
10 pcs |
||||
|
G5 |
12 |
2” |
white |
10 pcs |
||||
|
G5 |
18 |
2” |
black |
10 pcs |
||||
|
AIS Dual wall polyolefin tubing / AIS通用型含膠熱收縮套管 |
||||||||
|
ITEM NO. 產品名稱. |
Nominal Size(mm) 尺寸(毫米) |
Length(inch) 長度(英吋) |
Black & Quantity 黑色&數量 |
|||||
|
AIS |
4.8 |
2” |
20 PCS |
|||||
|
AIS |
12.7 |
2” |
5 PCS |
|||||
|
AIS |
25.4 |
2” |
2 PCS |
|||||
|
GAST-B 110˚C Solder Sleeve Wire Splices/ 防水銲錫環熱縮中接 |
||||||||
|
ITEM NO. 產品名稱. |
Cable Size(AWG)mm2 電線規格 |
Color & Quantity 彩色&數量 |
||||||
|
GAST-2 |
22-18(0.5-1.0) |
Red |
10 pcs |
|||||
|
GAST-3 |
16-14(1.5-2.5) |
Blue |
8 pcs |
|||||
|
GAST-4 |
12-10(4.0-6.0) |
Yellow |
6 pcs |
|||||
|
CRIMP Water Proof Heat Shrinkable Crimp Splices /防水熱縮中接管 |
||||||||
|
ITEM NO. 產品名稱 |
Cable Size(AWG)mm2 電線規格 |
Color & Quantity 彩色&數量 |
||||||
|
GBS-1 |
22-18(0.5-1.0) |
Red |
9pcs |
|||||
|
GBS-2 |
16-14(1.5-2.5) |
Blue |
7pcs |
|||||
|
GBS-5 |
12-10(4.0-6.0) |
Yellow |
6pcs |
|||||
|
ABS Watertight tube For Terminals And Crimp splices/ 防水端子用熱收縮套管 |
||||
|
ITEM NO. 產品名稱 |
Size(mm) 尺寸(毫米) |
Length(inch) 長度(英吋) |
Color & Quantity 彩色&數量 |
|
|
ABS48 |
4.8±0.3 |
1.6 |
Red |
9pcs |
|
ABS58 |
5.8±0.3 |
1.6 |
Blue |
7pcs |
|
ABS68 |
6.8±0.3 |
1.6 |
Yellow |
6pcs |
指定包裝可以客戶實際需求調整內容
Specified color and quantity on request
