APO-PBS 高彈性熱縮中接管
  • 應用
    APO-PBS是由改性聚烯烴生産而成的熱收縮套管塗膠而成黏接力對PVC,PE,金屬黏接力強用於保護連接,防水,抗腐蝕。 可以在粗糙的環境中加強固定和防震動,具有很好的絕緣保護電子連接器的功能。與常規的連接器相比,具有耐久性,易於安裝,安裝成本低的優勢。
    Made by modified polyolefin, with superior sealing for protecting splices from water and corrosion. Inner adhesive bonds to PVC,PE and metals. Providing strain relief and against vibration in rugged environments, which excellently insulates and protects electronic connections. It offers long-term performance, easy installation, and a low installed cost, which is more reliable than conventional crimp terminals.
  • 特性
    收縮率:3:1
    Polyamide熱融膠提供優異的防水性能
    材料優異的延伸性能,抗機械損害
    透明度佳提供更好的抗拉力
    高彈性體,管材不易變形
    Shrinkage ratio:3:1
    Hot melt adhesive provides waterproof property
    Excellent stretch and mechanical damage resistance
    Ideally translucent provides tensile strength
    High elasticity keeps steady performance
  • 操作溫度範圍
    工作溫度:-40℃ ~ 105℃
    開始收縮溫度 :60℃
    完全收縮溫度:100℃
    Operating Temp. -40℃~105℃
    Minimum Shrink Temp. 60℃
    Fully Recover Temp.100℃
  • 認證 / 規範
  • 顏色
    標準顏色:紅、藍、黃
    Standard color :Red、Blue、Yellow

Part Number.

產品型號

Nominal Size 尺寸 (mm)

Wire Range電線

Standard Color

標準顏色

A

B

L

A.W.G. (mm2)

PBS-1

4.7

1.7

35

22-18 (0.5-1.0)

Red 紅

PBS-2

5.7

2.4

36

16-14 (1.5-2.5)

Blue 藍

PBS-5

6.7

3.6

42

12-10 (4.0-6.0)

Yellow 黃

Crimping tool:CT2005

推薦壓著手工具:型號 CT2005
